This article describes shape analysis to analyze and process geometric shapes. == Description == Shape analysis is the (mostly) automatic analysis of geometric shapes, for example using a computer to detect similarly shaped objects in a database or parts that fit together. For a computer to automatically analyze and process geometric shapes, the objects have to be represented in a digital form. Most commonly a boundary representation is used to describe the object with its boundary (usually the outer shell, see also 3D model). However, other volume based representations (e.g. constructive solid geometry) or point based representations (point clouds) can be used to represent shape. Once the objects are given, either by modeling (computer-aided design), by scanning (3D scanner) or by extracting shape from 2D or 3D images, they have to be simplified before a comparison can be achieved. The simplified representation is often called a shape descriptor (or fingerprint, signature). These simplified representations try to carry most of the important information, while being easier to handle, to store and to compare than the shapes directly. A complete shape descriptor is a representation that can be used to completely reconstruct the original object (for example the medial axis transform). == Application fields == Shape analysis is used in many application fields: archeology for example, to find similar objects or missing parts architecture for example, to identify objects that spatially fit into a specific space medical imaging to understand shape changes related to illness or aid surgical planning virtual environments or on the 3D model market to identify objects for copyright purposes security applications such as face recognition entertainment industry (movies, games) to construct and process geometric models or animations computer-aided design and computer-aided manufacturing to process and to compare designs of mechanical parts or design objects. == Shape descriptors == Shape descriptors can be classified by their invariance with respect to the transformations allowed in the associated shape definition. Many descriptors are invariant with respect to congruency, meaning that congruent shapes (shapes that could be translated, rotated and mirrored) will have the same descriptor (for example moment or spherical harmonic based descriptors or Procrustes analysis operating on point clouds). Another class of shape descriptors (called intrinsic shape descriptors) is invariant with respect to isometry. These descriptors do not change with different isometric embeddings of the shape. Their advantage is that they can be applied nicely to deformable objects (e.g. a person in different body postures) as these deformations do not involve much stretching but are in fact near-isometric. Such descriptors are commonly based on geodesic distances measures along the surface of an object or on other isometry invariant characteristics such as the Laplace–Beltrami spectrum (see also spectral shape analysis). There are other shape descriptors, such as graph-based descriptors like the medial axis or the Reeb graph that capture geometric and/or topological information and simplify the shape representation but can not be as easily compared as descriptors that represent shape as a vector of numbers. From this discussion it becomes clear, that different shape descriptors target different aspects of shape and can be used for a specific application. Therefore, depending on the application, it is necessary to analyze how well a descriptor captures the features of interest.
Systems development life cycle
The systems development life cycle (SDLC) describes the typical phases and progression between phases during the development of a computer-based system. These phases progress from inception to retirement. At base, there is just one life cycle, but the taxonomy used to describe it may vary; the cycle may be classified into different numbers of phases and various names may be used for those phases. The SDLC is analogous to the life cycle of a living organism from its birth to its death. In particular, the SDLC varies by system in much the same way that each living organism has a unique path through its life. The SDLC does not prescribe how engineers should go about their work to move the system through its life cycle. Prescriptive techniques are referred to using various terms such as methodology, model, framework, and formal process. Other terms are used for the same concept as SDLC, including software development life cycle (also SDLC), application development life cycle (ADLC), and system design life cycle (also SDLC). These other terms focus on a different scope of development and are associated with different prescriptive techniques, but are about the same essential life cycle. The term "life cycle" is often written without a space, as "lifecycle", with the former more popular in the past and in non-engineering contexts. The acronym SDLC was coined when the longer form was more popular and has remained associated with the expansion, even though the shorter form is popular in engineering. Also, SDLC is relatively unique as opposed to the TLA SDL, which is highly overloaded. == Phases == Depending on the source, the SDLC is described as having different phases and using different terms. Even so, there are common aspects. The following attempts to describe notable phases using notable terminology. The phases are somewhat ordered by the natural sequence of development, although they can be overlapping and iterative. === Conceptualization === During conceptualization (a.k.a. conceptual design, system investigation, feasibility), options and priorities are considered. A feasibility study can determine whether the development effort is worthwhile via activities such as understanding user needs, cost estimation, benefit analysis, and resource analysis. A study should address operational, financial, technical, human factors, and legal/political concerns. === Requirements analysis === Requirements analysis (a.k.a. preliminary design) involves understanding the problem and determining what is needed. Often this involves engaging users to define the requirements and recording them in a document known as a requirements specification. === Design === During the design phase (a.k.a. detail design), a solution is planned. The plan can include relatively high-level information such as describing the major components of the system. The plan can include relatively low-level information such as describing functions, screen layout, business rules, and process flow. The design phase is informed by the requirements of the system. The design must satisfy each requirement. The design may be recorded in textual documents as well as functional hierarchy diagrams, example screen images, business rules, process diagrams, pseudo-code, and data models. === Construction === During construction (a.k.a. implementation, production), the system is realized. Based on the design, hardware and software components are created and integrated. This phase includes testing sub-components, components and the integration of some components, but typically does not include testing at the complete system level. This phase may include the development of training materials, including user manuals and help files. === Acceptance === The acceptance phase (a.k.a. system testing) is about testing the complete system to ensure that it meets customer expectations (requirements). === Deployment === The deployment phase (a.k.a. implementation) involves the logistics of delivery to the customer. Some systems are deployed as a single instance (i.e. in the cloud), and deployment may be ad hoc and manual. Some systems are built in quantity and are associated with manufacturing process and commissioning. This phase may include training users to use the system. It may include transitioning future development to support staff. === Maintenance === During the maintenance phase (a.k.a. operation, utilization, support) development is largely inactive, although this phase does include customer support for resolving user issues and recording suggestions for improvement. Fixes and enhancements are handled by returning to the first phase, conceptualization. For minor changes, the cycle may be significantly abbreviated compared to initial development. === Decommission === Decommission (a.k.a. disposition, retirement, phase-out) is when the system is removed from use, i.e., when it reaches end-of-life. == Practices == === Management and control === SDLC phase objectives are described in this section with key deliverables, a description of recommended tasks, and a summary of related control objectives for effective management. It is critical for the project manager to establish and monitor control objectives while executing projects. Control objectives are clear statements of the desired result or purpose and should be defined and monitored throughout a project. Control objectives can be grouped into major categories (domains), and relate to the SDLC phases as shown in the figure. To manage and control a substantial SDLC initiative, a work breakdown structure (WBS) captures and schedules the work. The WBS and all programmatic material should be kept in the "project description" section of the project notebook. The project manager chooses a WBS format that best describes the project. The diagram shows that coverage spans numerous phases of the SDLC, but the associated MCD (Management Control Domains) shows mappings to SDLC phases. For example, Analysis and Design is primarily performed as part of the Acquisition and Implementation Domain, and System Build and Prototype is primarily performed as part of delivery and support. === Work breakdown structured organization === The upper section of the WBS provides an overview of the project scope and timeline. It should also summarize the major phases and milestones. The middle section is based on the SDLC phases. WBS elements consist of milestones and tasks to be completed rather than activities to be undertaken, and have a deadline. Each task has a measurable output (e.g., an analysis document). A WBS task may rely on one or more activities (e.g., coding). Parts of the project needing support from contractors should have a statement of work (SOW). The development of an SOW does not occur during a specific phase of SDLC but is developed to include the work from the SDLC process that may be conducted by contractors. === Baselines === Baselines are established after four of the five phases of the SDLC, and are critical to the iterative nature of the model. Baselines become milestones. functional baseline: established after the conceptual design phase. allocated baseline: established after the preliminary design phase. product baseline: established after the detailed design and development phase. updated product baseline: established after the production construction phase. In the following diagram, these stages are divided into ten steps, from definition to creation and modification of IT work products:
Liquid state machine
A liquid state machine (LSM) is a type of reservoir computer that uses a spiking neural network. An LSM consists of a large collection of units (called nodes, or neurons). Each node receives time varying input from external sources (the inputs) as well as from other nodes. Nodes are randomly connected to each other. The recurrent nature of the connections turns the time varying input into a spatio-temporal pattern of activations in the network nodes. The spatio-temporal patterns of activation are read out by linear discriminant units. The soup of recurrently connected nodes will end up computing a large variety of nonlinear functions on the input. Given a large enough variety of such nonlinear functions, it is theoretically possible to obtain linear combinations (using the read out units) to perform whatever mathematical operation is needed to perform a certain task, such as speech recognition or computer vision. The word liquid in the name comes from the analogy drawn to dropping a stone into a still body of water or other liquid. The falling stone will generate ripples in the liquid. The input (motion of the falling stone) has been converted into a spatio-temporal pattern of liquid displacement (ripples). LSMs have been put forward as a way to explain the operation of brains. LSMs are argued to be an improvement over the theory of artificial neural networks because: Circuits are not hard coded to perform a specific task. Continuous time inputs are handled "naturally". Computations on various time scales can be done using the same network. The same network can perform multiple computations. Criticisms of LSMs as used in computational neuroscience are that LSMs don't actually explain how the brain functions. At best they can replicate some parts of brain functionality. There is no guaranteed way to dissect a working network and figure out how or what computations are being performed. There is very little control over the process. == Universal function approximation == If a reservoir has fading memory and input separability, with help of a readout, it can be proven the liquid state machine is a universal function approximator using Stone–Weierstrass theorem.
Mathematics of neural networks in machine learning
An artificial neural network (ANN) or neural network combines biological principles with advanced statistics to solve problems in domains such as pattern recognition and game-play. ANNs adopt the basic model of neuron analogues connected to each other in a variety of ways. == Structure == === Neuron === A neuron with label j {\displaystyle j} receiving an input p j ( t ) {\displaystyle p_{j}(t)} from predecessor neurons consists of the following components: an activation a j ( t ) {\displaystyle a_{j}(t)} , the neuron's state, depending on a discrete time parameter, an optional threshold θ j {\displaystyle \theta _{j}} , which stays fixed unless changed by learning, an activation function f {\displaystyle f} that computes the new activation at a given time t + 1 {\displaystyle t+1} from a j ( t ) {\displaystyle a_{j}(t)} , θ j {\displaystyle \theta _{j}} and the net input p j ( t ) {\displaystyle p_{j}(t)} giving rise to the relation a j ( t + 1 ) = f ( a j ( t ) , p j ( t ) , θ j ) , {\displaystyle a_{j}(t+1)=f(a_{j}(t),p_{j}(t),\theta _{j}),} and an output function f out {\displaystyle f_{\text{out}}} computing the output from the activation o j ( t ) = f out ( a j ( t ) ) . {\displaystyle o_{j}(t)=f_{\text{out}}(a_{j}(t)).} Often the output function is simply the identity function. An input neuron has no predecessor but serves as input interface for the whole network. Similarly an output neuron has no successor and thus serves as output interface of the whole network. === Propagation function === The propagation function computes the input p j ( t ) {\displaystyle p_{j}(t)} to the neuron j {\displaystyle j} from the outputs o i ( t ) {\displaystyle o_{i}(t)} and typically has the form p j ( t ) = ∑ i o i ( t ) w i j . {\displaystyle p_{j}(t)=\sum _{i}o_{i}(t)w_{ij}.} === Bias === A bias term can be added, changing the form to the following: p j ( t ) = ∑ i o i ( t ) w i j + w 0 j , {\displaystyle p_{j}(t)=\sum _{i}o_{i}(t)w_{ij}+w_{0j},} where w 0 j {\displaystyle w_{0j}} is a bias. == Neural networks as functions == Neural network models can be viewed as defining a function that takes an input (observation) and produces an output (decision) f : X → Y {\displaystyle \textstyle f:X\rightarrow Y} or a distribution over X {\displaystyle \textstyle X} or both X {\displaystyle \textstyle X} and Y {\displaystyle \textstyle Y} . Sometimes models are intimately associated with a particular learning rule. A common use of the phrase "ANN model" is really the definition of a class of such functions (where members of the class are obtained by varying parameters, connection weights, or specifics of the architecture such as the number of neurons, number of layers or their connectivity). Mathematically, a neuron's network function f ( x ) {\displaystyle \textstyle f(x)} is defined as a composition of other functions g i ( x ) {\displaystyle \textstyle g_{i}(x)} , that can further be decomposed into other functions. This can be conveniently represented as a network structure, with arrows depicting the dependencies between functions. A widely used type of composition is the nonlinear weighted sum, where f ( x ) = K ( ∑ i w i g i ( x ) ) {\displaystyle \textstyle f(x)=K\left(\sum _{i}w_{i}g_{i}(x)\right)} , where K {\displaystyle \textstyle K} (commonly referred to as the activation function) is some predefined function, such as the hyperbolic tangent, sigmoid function, softmax function, or rectifier function. The important characteristic of the activation function is that it provides a smooth transition as input values change, i.e. a small change in input produces a small change in output. The following refers to a collection of functions g i {\displaystyle \textstyle g_{i}} as a vector g = ( g 1 , g 2 , … , g n ) {\displaystyle \textstyle g=(g_{1},g_{2},\ldots ,g_{n})} . This figure depicts such a decomposition of f {\displaystyle \textstyle f} , with dependencies between variables indicated by arrows. These can be interpreted in two ways. The first view is the functional view: the input x {\displaystyle \textstyle x} is transformed into a 3-dimensional vector h {\displaystyle \textstyle h} , which is then transformed into a 2-dimensional vector g {\displaystyle \textstyle g} , which is finally transformed into f {\displaystyle \textstyle f} . This view is most commonly encountered in the context of optimization. The second view is the probabilistic view: the random variable F = f ( G ) {\displaystyle \textstyle F=f(G)} depends upon the random variable G = g ( H ) {\displaystyle \textstyle G=g(H)} , which depends upon H = h ( X ) {\displaystyle \textstyle H=h(X)} , which depends upon the random variable X {\displaystyle \textstyle X} . This view is most commonly encountered in the context of graphical models. The two views are largely equivalent. In either case, for this particular architecture, the components of individual layers are independent of each other (e.g., the components of g {\displaystyle \textstyle g} are independent of each other given their input h {\displaystyle \textstyle h} ). This naturally enables a degree of parallelism in the implementation. Networks such as the previous one are commonly called feedforward, because their graph is a directed acyclic graph. Networks with cycles are commonly called recurrent. Such networks are commonly depicted in the manner shown at the top of the figure, where f {\displaystyle \textstyle f} is shown as dependent upon itself. However, an implied temporal dependence is not shown. == Backpropagation == Backpropagation training algorithms fall into three categories: steepest descent (with variable learning rate and momentum, resilient backpropagation); quasi-Newton (Broyden–Fletcher–Goldfarb–Shanno, one step secant); Levenberg–Marquardt and conjugate gradient (Fletcher–Reeves update, Polak–Ribiére update, Powell–Beale restart, scaled conjugate gradient). === Algorithm === Let N {\displaystyle N} be a network with e {\displaystyle e} connections, m {\displaystyle m} inputs and n {\displaystyle n} outputs. Below, x 1 , x 2 , … {\displaystyle x_{1},x_{2},\dots } denote vectors in R m {\displaystyle \mathbb {R} ^{m}} , y 1 , y 2 , … {\displaystyle y_{1},y_{2},\dots } vectors in R n {\displaystyle \mathbb {R} ^{n}} , and w 0 , w 1 , w 2 , … {\displaystyle w_{0},w_{1},w_{2},\ldots } vectors in R e {\displaystyle \mathbb {R} ^{e}} . These are called inputs, outputs and weights, respectively. The network corresponds to a function y = f N ( w , x ) {\displaystyle y=f_{N}(w,x)} which, given a weight w {\displaystyle w} , maps an input x {\displaystyle x} to an output y {\displaystyle y} . In supervised learning, a sequence of training examples ( x 1 , y 1 ) , … , ( x p , y p ) {\displaystyle (x_{1},y_{1}),\dots ,(x_{p},y_{p})} produces a sequence of weights w 0 , w 1 , … , w p {\displaystyle w_{0},w_{1},\dots ,w_{p}} starting from some initial weight w 0 {\displaystyle w_{0}} , usually chosen at random. These weights are computed in turn: first compute w i {\displaystyle w_{i}} using only ( x i , y i , w i − 1 ) {\displaystyle (x_{i},y_{i},w_{i-1})} for i = 1 , … , p {\displaystyle i=1,\dots ,p} . The output of the algorithm is then w p {\displaystyle w_{p}} , giving a new function x ↦ f N ( w p , x ) {\displaystyle x\mapsto f_{N}(w_{p},x)} . The computation is the same in each step, hence only the case i = 1 {\displaystyle i=1} is described. w 1 {\displaystyle w_{1}} is calculated from ( x 1 , y 1 , w 0 ) {\displaystyle (x_{1},y_{1},w_{0})} by considering a variable weight w {\displaystyle w} and applying gradient descent to the function w ↦ E ( f N ( w , x 1 ) , y 1 ) {\displaystyle w\mapsto E(f_{N}(w,x_{1}),y_{1})} to find a local minimum, starting at w = w 0 {\displaystyle w=w_{0}} . This makes w 1 {\displaystyle w_{1}} the minimizing weight found by gradient descent. == Learning pseudocode == To implement the algorithm above, explicit formulas are required for the gradient of the function w ↦ E ( f N ( w , x ) , y ) {\displaystyle w\mapsto E(f_{N}(w,x),y)} where the function is E ( y , y ′ ) = | y − y ′ | 2 {\displaystyle E(y,y')=|y-y'|^{2}} . The learning algorithm can be divided into two phases: propagation and weight update. === Propagation === Propagation involves the following steps: Propagation forward through the network to generate the output value(s) Calculation of the cost (error term) Propagation of the output activations back through the network using the training pattern target to generate the deltas (the difference between the targeted and actual output values) of all output and hidden neurons. === Weight update === For each weight: Multiply the weight's output delta and input activation to find the gradient of the weight. Subtract the ratio (percentage) of the weight's gradient from the weight. The learning rate is the ratio (percentage) that influences the speed and quality of learning. The greater the ratio, the faster the neuron trains, but the lower the ratio, the more accurat
Weighted majority algorithm (machine learning)
In machine learning, weighted majority algorithm (WMA) is a meta learning algorithm used to construct a compound algorithm from a pool of prediction algorithms, which could be any type of learning algorithms, classifiers, or even real human experts. The algorithm assumes that we have no prior knowledge about the accuracy of the algorithms in the pool, but there are sufficient reasons to believe that one or more will perform well. Assume that the problem is a binary decision problem. To construct the compound algorithm, a positive weight is given to each of the algorithms in the pool. The compound algorithm then collects weighted votes from all the algorithms in the pool, and gives the prediction that has a higher vote. If the compound algorithm makes a mistake, the algorithms in the pool that contributed to the wrong predicting will be discounted by a certain ratio β where 0<β<1. It can be shown that the upper bounds on the number of mistakes made in a given sequence of predictions from a pool of algorithms A {\displaystyle \mathbf {A} } is O ( l o g | A | + m ) {\displaystyle \mathbf {O(log|A|+m)} } if one algorithm in x i {\displaystyle \mathbf {x} _{i}} makes at most m {\displaystyle \mathbf {m} } mistakes. There are many variations of the weighted majority algorithm to handle different situations, like shifting targets, infinite pools, or randomized predictions. The core mechanism remains similar, with the final performances of the compound algorithm bounded by a function of the performance of the specialist (best performing algorithm) in the pool.
Data event
A data event is a relevant state transition defined in an event schema. Typically, event schemata are described by pre- and post condition for a single or a set of data items. In contrast to ECA (Event condition action), which considers an event to be a signal, the data event not only refers to the change (signal), but describes specific state transitions, which are referred to in ECA as conditions. Considering data events as relevant data item state transitions allows defining complex event-reaction schemata for a database. Defining data event schemata for relational databases is limited to attribute and instance events. Object-oriented databases also support collection properties, which allows defining changes in collections as data events, too.
SqueezeNet
SqueezeNet is a deep neural network for image classification released in 2016. SqueezeNet was developed by researchers at DeepScale, University of California, Berkeley, and Stanford University. In designing SqueezeNet, the authors' goal was to create a smaller neural network with fewer parameters while achieving competitive accuracy. Their best-performing model achieved the same accuracy as AlexNet on ImageNet classification, but has a size 510x less than it. == Version history == SqueezeNet was originally released on February 22, 2016. This original version of SqueezeNet was implemented on top of the Caffe deep learning software framework. Shortly thereafter, the open-source research community ported SqueezeNet to a number of other deep learning frameworks. On February 26, 2016, Eddie Bell released a port of SqueezeNet for the Chainer deep learning framework. On March 2, 2016, Guo Haria released a port of SqueezeNet for the Apache MXNet framework. On June 3, 2016, Tammy Yang released a port of SqueezeNet for the Keras framework. In 2017, companies including Baidu, Xilinx, Imagination Technologies, and Synopsys demonstrated SqueezeNet running on low-power processing platforms such as smartphones, FPGAs, and custom processors. As of 2018, SqueezeNet ships "natively" as part of the source code of a number of deep learning frameworks such as PyTorch, Apache MXNet, and Apple CoreML. In addition, third party developers have created implementations of SqueezeNet that are compatible with frameworks such as TensorFlow. Below is a summary of frameworks that support SqueezeNet. == Relationship to other networks == === AlexNet === SqueezeNet was originally described in SqueezeNet: AlexNet-level accuracy with 50x fewer parameters and <0.5MB model size. AlexNet is a deep neural network that has 240 MB of parameters, and SqueezeNet has just 5 MB of parameters. This small model size can more easily fit into computer memory and can more easily be transmitted over a computer network. However, it's important to note that SqueezeNet is not a "squeezed version of AlexNet." Rather, SqueezeNet is an entirely different DNN architecture than AlexNet. What SqueezeNet and AlexNet have in common is that both of them achieve approximately the same level of accuracy when evaluated on the ImageNet image classification validation dataset. === Model compression === Model compression (e.g. quantization and pruning of model parameters) can be applied to a deep neural network after it has been trained. In the SqueezeNet paper, the authors demonstrated that a model compression technique called Deep Compression can be applied to SqueezeNet to further reduce the size of the parameter file from 5 MB to 500 KB. Deep Compression has also been applied to other DNNs, such as AlexNet and VGG. == Variants == Some of the members of the original SqueezeNet team have continued to develop resource-efficient deep neural networks for a variety of applications. A few of these works are noted in the following table. As with the original SqueezeNet model, the open-source research community has ported and adapted these newer "squeeze"-family models for compatibility with multiple deep learning frameworks. In addition, the open-source research community has extended SqueezeNet to other applications, including semantic segmentation of images and style transfer.
